Industrial Gas Generators
Reliable High-Performance Gas Generators
Wusqa Technologies is a well-known and experienced organization that provides vendor
neutral products and solutions. We as trusted partnership with clients and in-depth
knowledge of their process, requirements, goals and specific market have ensured our
success. Our comprehensive problem-solving approach keeps us as end users preferred
partner in their growth and development. Our product offerings are supported from
Internationally accredited manufacturers of instrumentation, valves, pumps and steam
products often included in our engineered skid packages.
Wusqa Technologies
specializes in providing premium quality products that are engineered to excel in
the
most demanding industry applications. Our offerings are robust, designed to
withstand
the rigors of challenging environments.
.png)
99.5% Purity Dual Stage PSA Oxygen Generator
- The Dual Stage, High Purity Pressure Swing Adsorption (PSA) Oxygen Generating Process separates oxygen from compressed air, which consists of 21% oxygen, 78% nitrogen, 0.9% argon, and 0.1% other gases.
- Utilizes a two-stage PSA process to generate up to 99.5% pure oxygen.
- Stage One: Uses molecular sieves (synthetic zeolite) to adsorb nitrogen at high pressure and desorb it at low pressure, producing up to 96% pure oxygen.
- Stage Two: Further purifies oxygen (95–96%) using activated carbon sieves to achieve up to 99.5% purity by adsorbing oxygen and releasing it at low pressure.
- Argon separation after Stage Two increases oxygen purity up to 99%.
- Carbon molecular sieves (CMS) help scrub impurities, enabling maximum achievable purity of 99.5%.
- Typically operated at a design point of 99.0% to optimize output, though this results in about 35% loss from the original 95% oxygen stream.
- Lower target purity results in less product loss.
- Fully automated with smart valves and microprocessor controls for precise operation.
- For 99% purity output, generators must have at least double the capacity due to product loss during purification.
Reliable and Cost-Effective Nitrogen Generation
- Cost-effective solution for on-site nitrogen generation.
- Eliminates cylinder rental, refills, and delivery costs.
- Minimal maintenance and easy operation.
- Ideal for small to large-scale businesses.
- Advanced membrane separation technology for high-purity nitrogen.
- Ensures uninterrupted nitrogen supply as needed.
High-Purity Nitrogen Using PSA Technology
- Employs Pressure Swing Adsorption (PSA) with Carbon Molecular Sieve (CMS).
- Air is compressed to 10 bars via compressors.
- Moisture removed using refrigerant or desiccant dryers.
- Filtration system removes particles, oil, and aerosols.
- Carbon Tower ensures consistent oil-free nitrogen output.
- Two CMS tanks operate in pressurization, generation, equalization, and exhaust cycles.
- Delivers continuous, high-purity nitrogen for industrial applications.
Ensuring Ultra-Clean, Odor-Free Compressed Air
- Removes oil-aerosols, oil vapors, odors, and tastes using high-porosity activated carbon.
- Installed after air dryers and pre-filters for optimal performance.
- Achieves Class 1 air purity with residual oil content below 0.01 mg/m³ as per ISO 8573-1.
- Ideal for sensitive industries: optical, electronics, food, pharma, and surface technologies.
- Compact, maintenance-free, free-standing unit design.
- Compressed air flows from top to bottom through CarboTech activated carbon.
- Final stage includes an after-filter to remove particulates down to 0.003 mg/m³ oil content.
Reliable Moisture Removal for Compressed Air Systems
- Compressed air is always 100% saturated, leading to moisture issues upon cooling.
- Excessive moisture causes corrosion and premature failure of pneumatic systems.
- Desiccant dryers ensure dry air with pressure dew points ranging from 0°C to -72°C.
- Air is compressed to 7–13 bars, filtered for particles, oil, and condensed water.
- Drying is achieved through PSA tanks filled with Activated Alumina and Zeolites.
- Each PSA tank operates in pressurization, drying, and exhaust cycles for continuous drying.
- Desiccants adsorb moisture; regeneration is performed by depressurizing the saturated tower.
